MD Exports LLP Specialist in Nickel 201 Welded Pipe., Pipes Tubes are manufactured using superior grade of Nickel like Nickel 200 Pipe, Nickel 200 Seamless Pipes, Nickel 200 Welded Pipes, Nickel 200 Pipe, Nickel 201 Pipe, Nickel 201 Seamless Pipes, Nickel 201 Welded Pipes, Nickel 201 Pipe, These Tubing are most durable and manufactures to fit in different size of Pipes. Engineers & World's Best Project Consultants use these Nickel Pipe in Machined Components, MD Exports LLP Specialized Nickel 201 Welded Pipe & supplying to Government sector companies since 2 decades,we are approved vendor of Nickel 201 Welded Pipe in top notch government sector companies like ONGC, Indian Oil,NTPC,BHEL,ONGC,HPCL BPCL etc.we are also Saudi Aramco approved supplier of Nickel 201 Welded Pipe, we have supplied Nickel 201 Welded Pipe to companies involved in Equipment Manufacturing, Mining, Oil Refineries, Chemical manufacturing, Steel and Alloy Steel Manufacturing, Utilities and Transportation, and Industrial Construction We Also Supply & Maintain huge stock of Other Grades of like Stainless Steel Pipe Tube, Alloy Steel Pipe Tube Tuberia, Inconel Pipe Tube Tubing, Monel Pipe Tube Tubing, Hastelloy Pipe Tube Tubing, Nickel Pipe Tube Tubing, Alloy Steel Pipe Tube Tubing Etc.
We stock approximately 1000 tonnes of high quality certified Nickel 201 Welded Pipe in numerous sizes and materials which can be packed and shipped to any destination worldwide.
Nickel 201 Welded Pipe
Specification :
Size : 1/8"NB TO 30"NB IN
Standards : ASTM / ASME
Grades : UNS 2200 (Nickel 200), UNS 2201 (Nickel 201)
Length : Double Random, Single Random, Cut Length
Type : Seamless, Welded, Fabricated, ERW, LSAW Pipes
Form : Round, Rectangular, Hydraulic, Square
Types of Nickel Alloys Pipes & Tubes :
Nickel Alloy 200 (UNS No. N02200) Pipes & Tubes / Tubing
Nickel Alloy 201 (UNS No. N02201) Pipes & Tubes / Tubing
Features :
• Excellent mechanical & magnetic properties
• High thermal & electrical conductivity
• Low gas content & vapor- pressure
• Value Added Services
• Hot Dipped Galvanizing
• Epoxy & Fbe Coating
• Electro Polish
• Draw & Expansion
ASTM B 725 Nickel 201 Welded Pipe Specification
| Standards | Seamless |
| ASTM | B 725 |
| ASME | SB 725 |
| NB Sizes | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
|---|---|---|---|---|---|
| Nickel 201 Welded Pipe 1/8″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | |
| Nickel 201 Welded Pipe 1/4″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | |
| Nickel 201 Welded Pipe 3/8″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | |
| Nickel 201 Welded Pipe 1/2″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| Nickel 201 Welded Pipe 3/4″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| Nickel 201 Welded Pipe 1″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| Nickel 201 Welded Pipe 1 1/4″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| Nickel 201 Welded Pipe 1 1/2″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| Nickel 201 Welded Pipe 2″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| Nickel 201 Welded Pipe 2 1/2″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| Nickel 201 Welded Pipe 3″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| Nickel 201 Welded Pipe 4″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| Nickel 201 Welded Pipe 5″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 | |
| Nickel 201 Welded Pipe 6″ | Sch 5 | Sch 10 | Sch 40 | Sch 80 |
* The Following must be included with the ASTM designation and graded for the description to be complete:
WP (S) = Seamless
WP (W) = Welded
WP (WX) = Welded with 100% x-ray
WP (U) = Welded with 100% Ultrasonic examination
CR = Corrosion resistant in acordance with MSS SP-43
Nickel Alloy Specifications especially in pipe and tube refer only to the UNS number for material identification. Classes and Grades are occasionally used to identify options for items such as NDT, heat treatment or different methods employed when welding with filler metal such as single welded or double welded. These options do not result in an additional UNS number in the nickel materials.
Grades/Classes/Identification Symbols are shown in this table only when they are used for material identification.
When availability of starting material is a problem, some manufacturers will offer valves machined from Nickel 200 and 201. Customer approval may be required.
Data in this table (except for Valve Castings) was taken from the 2013 editions, Section One Volume 01.01 and Section Two Volume 02.04, of the annual book of ASTM Standards. Casting Specification Data was from Volume 01.02, same edition.
Nickel 200 Specifications
| Standard | Nickel 200 | Nickel 201 |
|---|---|---|
| UNS | N02200 | N02201 |
| Werkstoff Nr. | 2.4066 | 2.4068 |
Nickel 200 Chemical Composition
| Nickel 200 | Nickel 201 | |
| Ni | 99.0 min | 99.0 min |
| Fe | 0.4 max | 0.4 max |
| C | 0.15 max | 0.02 max |
| Mn | 0.35 max | 0.35 max |
| Si | 0.1 max | 0.2 max |
| Cu | 0.25 max | 0.25 max |
| Mg | 0.15 max | |
| Ti | 0.1 max | |
| S | 0.01 max | 0.01 max |
Nickel 200 Mechanical & Physical Properties
| Density | 8.9 g/cm3 |
| Melting Point | 1446 °C (2635 °F) |
| Tensile Strength | Psi – 67000 , MPa – 462 |
| Yield Strength (0.2%Offset) | Psi – 21500 , MPa – 148 |
| Elongation | 45 % |
Packaging & Shipping
Utmost care is taken towards Packing of the Nickel 201 Welded Pipe so as to ensure that the resultant Coils, Foils, Tubes, Pipes and Fittings reach in the same condition as desired by our valued customers.
Packing specifications for various products are:
Larger Dia Fusion Welded Pipes are packed with aluminium end caps in a wooden crates.
S.S. Automotive Exhaust Pipes & Scheduled pipes both are packed with plastic end caps in wooden crates.
Cold Drawn Seamless Stainless Tubes are packed with plastic end caps in a wooden box with an inside thermocoal covering.
Coils and Foils are packed in wooden crates.
Bundle Packing
Wooden Case
Wooden Case for U Tubes
Reinforced by angle bar
To find out more about our Nickel 201 Welded Pipe, and get more information please fill enquiry form and one of our sales representatives will contact you.
