MD Exports LLP Specialized in AS Astm A335 Grade P92 Alloy Steel Seamless Pipe, which are manufactured using superior grade of steel like Stainless Steel 304,304L,310,310S,316,316L,317L. These Tubing are most durable and manufactures to fit in different size of Pipes. Engineers & World's Best Project Consultants use these stainless steel Tubing in Machined Components, MD Exports LLP manufacturing AS Astm A335 Grade P92 Alloy Steel Seamless Pipe & supplying to Government sector companies since 2 decades,we are approved vendor of AS Astm A335 Grade P92 Alloy Steel Seamless Pipe in top notch government sector companies like ONGC, Indian Oil,NTPC,BHEL,ONGC,HPCL BPCL etc.we are also Saudi Aramco approved supplier of AS Astm A335 Grade P92 Alloy Steel Seamless Pipe, we have supplied Stainless AS Astm A335 Grade P92 Alloy Steel Seamless Pipe to companies involved in Equipment Manufacturing, Mining, Oil Refineries, Chemical manufacturing, Steel and Alloy Steel Manufacturing, Utilities and Transportation, and Industrial Construction We Also Supply & Maintain huge stock of Other Grades of AS Astm A335 Grade P92 Alloy Steel Seamless Pipe like Stainless Steel, Alloy Steel Tuberia, Inconel Pipe Tube, Monel Pipe Tube, Hastelloy Pipe Tube, Nickel Pipe Tube, Alloy Steel Pipe Tube, Stainless Steel Seamless Pipes Tube Tubing Tuberia.
We stock approximately 1000 tonnes of high quality certified AS Astm A335 Grade P92 Alloy Steel Seamless Pipe in numerous sizes and materials which can be packed and shipped to any destination worldwide.
ASTM A335 P92 Alloy Steel Seamless Pipes
ASTM A335 / ASTM A450 / ASTM A530 Grade P92 Alloy Steel Seamless Pipes Manufacturer, Exporter & Suppliers.
ANSI B 36.10, Alloy Steel Gr. P92 Seamless Round, Square, Rectangular, Hydraulic Pipes Suppliers in India.
MD Exports LLP is leading Manufacturers, Supplier and Exporters of ASTM A335 P92 Alloy Steel Seamless Pipes . The range of ASTM A335 P92 seamless alloy steel pipe sizes that may be examined by each method shall be subjected to the limitations in the scope of the respective practice. These seamless pipe is used mainly for for High-Temperature Service. These pipes are widely used in different various application such as oil & gas, power plants, ship building, heavy engineering industries etc. These pipes are available in different size, specification, grades & thikness as per the clients requirements.
Specification :
| Size | : | 1/8NB TO 24NB IN |
| Standards | : | ASTM A 335, ASME SA 335 |
| Type | : | Seamless |
| Specialized in | : | Large Diameter Size |
| Outer Dimensions | : | 19.05mm – 114.3mm |
| Wall Thickness | : | 2.0mm – 14 mm |
| Length | : | max 16000mm |
| Schedule | : | Schedule 20 - Schedule XXS (heavier on request) up to 250 mm thk. |
| Form | : | Round, Square, Rectangular, Hydraulic Etc. |
| Length | : | Single Random, Double Random & Cut Length. |
| Tubing End | : | Plain End, Beveled End, Treaded. |
Chemical Compositions :
| C, % | Mn, % | P, % | S, % | Si, % | Cr, % | Mo, % | V, % | N, % | Ni, % | Al, % | Nb, % | W, % | B, % |
| 0.07-0.13 | 0.3-0.6 | 0.02 max | 0.01 max | 0.5 max | 8.5-9.5 | 0.3-0.6 | 0.15-0.25 | 0.03-0.07 | 0.4 max | 0.04 max | 0.04-0.09 | 1.5-2.0 | 0.001-0.006 |
Mechanical Properties :
| Tensile Strength , MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
| 620 min | 440 min | 20 min | 250 max |
Outside Diameter & Tolerance :
| ASTM A450 | Hot rolled | Outside Diameter, mm | Tolerance, mm |
| OD≤101.6 | +0.4/-0.8 | ||
| 101.6＜OD≤190.5 | +0.4/-1.2 | ||
| 190.5＜OD≤228.6 | +0.4/-1.6 | ||
| Cold Drawn | Outside Diameter, mm | Tolerance, mm | |
| OD＜25.4 | ±0.10 | ||
| 25.4≤OD≤38.1 | ±0.15 | ||
| 38.1＜OD＜50.8 | ±0.20 | ||
| 50.8≤OD＜63.5 | ±0.25 | ||
| 63.5≤OD＜76.2 | ±0.30 | ||
| 76.2≤OD≤101.6 | ±0.38 | ||
| 101.6＜OD≤190.5 | +0.38/-0.64 | ||
| 190.5＜OD≤228.6 | +0.38/-1.14 | ||
| ASTM A530 & ASTM A335 | NPS | Outside Diameter, inch | Tolerance, mm |
| 1/8≤OD≤1-1/2 | ±0.40 | ||
| 1-1/2＜OD≤4 | ±0.79 | ||
| 4＜OD≤8 | +1.59/-0.79 | ||
| 8＜OD≤12 | +2.38/-0.79 | ||
| OD>12 | ±1% |
Wall thickness & Tolerance :
| ASTM A450 | Hot rolled | Outside Diameter, mm | Tolerance, % |
| OD≤101.6, WT≤2.4 | +40/-0 | ||
| OD≤101.6, 2.4＜WT≤3.8 | +35/-0 | ||
| OD≤101.6, 3.8＜WT≤4.6 | +33/-0 | ||
| OD≤101.6, WT>4.6 | +28/-0 | ||
| OD>101.6, 2.4＜WT≤3.8 | +35/-0 | ||
| OD>101.6, 3.8＜WT≤4.6 | +33/-0 | ||
| OD>101.6, WT>4.6 | +28/-0 | ||
| Cold Drawn | Outside Diameter, mm | Tolerance, % | |
| OD≤38.1 | +20/-0 | ||
| OD>38.1 | +22/-0 | ||
| ASTM A530 | NPS | Outside Diameter, inch | Tolerance, % |
| 1/8≤OD≤2-1/2 | +20.0/-12.5 | ||
| 3≤OD≤18, WT/OD≤5% | +22.5/-12.5 | ||
| 3≤OD≤18, WT/OD>5% | +15.0/-12.5 | ||
| OD≥20, WT/OD≤5% | +22.5/-12.5 | ||
| OD≥20, WT/OD>5% | +15.0/-12.5 |
To find out more about our AS Astm A335 Grade P92 Alloy Steel Seamless Pipe, and get more information please fill enquiry form and one of our sales representatives will contact you.
