MD Exports LLP Specialist in Inconel Alloy 601 Tube Tubing., Pipes Tubes are manufactured using superior grade of Inconel like Alloy 600 Tube / Tubing / Tuberia, Alloy 601 Tube / Tubing / Tuberia, Alloy 625 Tube / Tubing / Tuberia, Incoloy 800 Tube / Tubing / Tuberia, Incoloy 825 Tube / Tubing / Tuberia, Alloy 718 Tube / Tubing / Tuberia, Inconel X-750 Tube / Tubing / Tuberia, These Tubing are most durable and manufactures to fit in different size of Pipes. Engineers & World's Best Project Consultants use these Inconel Tube / Tubing / Tuberia in Machined Components, MD Exports LLP Specialized Inconel Alloy 601 Tube Tubing & supplying to Government sector companies since 2 decades,we are approved vendor of Inconel Alloy 601 Tube Tubing in top notch government sector companies like ONGC, Indian Oil,NTPC,BHEL,ONGC,HPCL BPCL etc.we are also Saudi Aramco approved supplier of Inconel Alloy 601 Tube Tubing, we have supplied Inconel Alloy 601 Tube Tubing to companies involved in Equipment Manufacturing, Mining, Oil Refineries, Chemical manufacturing, Steel and Alloy Steel Manufacturing, Utilities and Transportation, and Industrial Construction We Also Supply & Maintain huge stock of Other Grades of like Stainless Steel Pipe Tube, Alloy Steel Pipe Tube Tuberia, Inconel Pipe Tube Tubing, Monel Pipe Tube Tubing, Hastelloy Pipe Tube Tubing, Nickel Pipe Tube Tubing, Alloy Steel Pipe Tube Tubing Etc.
We stock approximately 1000 tonnes of high quality certified Inconel Alloy 601 Tube Tubing in numerous sizes and materials which can be packed and shipped to any destination worldwide., We provide Inconel Alloy 601 Tube Tubing in all shapes and sizes and with any specifications that the clients || MD Exports LLP Specialized in Inconel Alloy 601 Tube Tubing in India, Ready Stock Available in Inconel Alloy 601 Tube Tubing in Mumbai India.
601 Inconel
Inconel 601 is a nickel-chromium alloy, that is highly resistant to oxidation through 2200°F. 601 alloy develops a tightly adherent oxide scale which resists spalling even under severe thermal cycling. The alloy has good high temperature strength, and retains its ductility after long service exposure. 601 alloy has good hot corrosion resistance under oxidizing conditions. 601 alloy is not suggested for use in strongly reducing, sulfur bearing environments.
For maximum oxidation resistance, 601 alloy should be welded with matching composition 601 alloy GTAW wire. The weld fillers developed for RA 602 CA can also provide a weld which is stronger and more oxidation resistant than the 601 alloy base metal. 601 alloy is more difficult to machine than 304 stainless steel. Its machinability rating is 15-21% relative to AISI B1112 steel.
Chemistry
| Ni | Cr | Al | C | Mn | Cu | Si | S | Fe | |
|---|---|---|---|---|---|---|---|---|---|
| MIN | 58.00 | 21.00 | 1.00 | -- | -- | -- | -- | -- | -- |
| MAX | 63.00 | 25.00 | 1.70 | 0.10 | 1.00 | 1.00 | 0.50 | 0.015 | Balance |
*ASTM specification 0.20 max C.
Specifications
AMS 5715, AMS 5870 ASME SB 167, ASME SB 168 ASTM B 167, ASTM B 168 EN 2.4851 UNS N06601 Werkstoff 2.4851
Inventory
601 Coil, 601 Pipe, 601 Plate, 601 Sheet
Common Trade Names
Alloy 601, Inconel® 601, Nickel 601
Features
Outstanding oxidation resistance to 2200°F
Highly resistant to carburization
Good creep and rupture strength
Metallurgical stability
Applications
Copper brazing, annealing and sintering muffles and retorts
Radiant tubes
Strand annealing tubes
Steam superheater tube supports
Rotary kilns and calciners
Thermocouple protection tubes
Physical Properties
Density: 0.293 lb/in3
Melting Point: 2375 - 2495°F
| Temperature, °F | 70 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 |
| Coefficient* of Thermal Expansion, in/in°F x 10-6 | - | 8.5 | 8.9 | 9.2 | 9.5 | 9.8 | 10.2 |
| Thermal Conductivity Btu • ft/ft2 • hr • °F |
6.5 | 11.6 | 12.7 | 13.7 | 14.8 | 15.8 | 16.9 |
| Modulus of Elasticity, Dynamic psi x 106 | 29.95 | 25.43 | 24.12 | 22.48 | 20.54 | 18.43 | 16.20 |
* 70°F to indicated temperature.
Mechanical Properties
Short-Time Elevated Temperature Tensile Properties
| Temperature,°F | 70 | 1000 | 1200 | 1400 | 1600 |
| Ultimate Tensile Strength, ksi | 100 | 90 | 60 | 34 | 18 |
| 0.2% Yield Strength, ksi | 54 | 48 | 41 | 26 | 15 |
| Elongation, % | 45 | 44 | 45 | 70 | 120 |
To find out more about our Inconel Alloy 601 Tube Tubing, and get more information please fill enquiry form and one of our sales representatives will contact you.
Typical Creep - Rupture Properties
| Temperature, °F | 1400 | 1600 | 1800 | 2000 |
| Minimum Creep 0.0001%/Hour, ksi | 4.1 | 2.0 | 0.76 | 0.43 |
| 10,000 Hour Rupture Strength, ksi | 6.2 | 2.6 | 1.2 | 0.62* |
* Extrapolated
INCONEL® and INCOLOY® are registered trademarks of Special Metals (PCC)
Available Inconel Tubes & Pipes in Stock
ASTM B 163 Inconel 600 Seamless PipeASTM B 166 Inconel 600 Seamless Tube
ASTM B 751 Inconel 600 Welded Pipe
ASTM B 775 Inconel 600 Welded Tube
ASTM B 167 Inconel 601 Seamless Pipe
ASTM B 167 Inconel 601 Seamless Tube
ASTM B 751 Inconel 601 Welded Pipe
ASTM B 775 Inconel 601 Welded Tube
ASTM B 444 Inconel 625 Seamless Pipe
ASTM B 444 Inconel 625 Seamless Tube
ASTM B 704 / 751 Inconel 625 Welded Pipe
ASTM B 705 / 751 Inconel 625 Welded Tube
ASTM B 407 Incoloy 800 Seamless Pipe
ASTM B 163 Incoloy 800 Seamless Tube
ASTM B 358 Incoloy 800 Welded Pipe
ASTM B 515 Incoloy 800 Welded Tube
ASTM B 407 Incoloy 800H Seamless Pipe
ASTM B 163 Incoloy 800H Seamless Tube
ASTM B 358 Incoloy 800H Welded Pipe
ASTM B 515 Incoloy 800H Welded Tube
ASTM B 407 Incoloy 800HT Seamless Pipe
ASTM B 163 Incoloy 800HT Seamless Tube
ASTM B 358 Incoloy 800HT Welded Pipe
ASTM B 515 Incoloy 800HT Welded Tube
ASTM B 163 Incoloy 825 Seamless Pipe
ASTM B 423 Incoloy 825 Seamless Tube
ASTM B 704 Incoloy 825 Welded Pipe
ASTM B 705 Incoloy 825 Welded Tube
To find out more about our Inconel Alloy 601 Tube Tubing, and get more information please fill enquiry form and one of our sales representatives will contact you.
